Features

• High speed switching. (Tf: Typ.: 30ns at IC = 3A)

• Low saturation voltage,typically (Typ.: 200mVatlC= 2A.1B=200mA)


• Strongdischarge power for inductive load and capacitance load.


• Complements the 2SA2071.


Applications

• NPN Silicon epitaxial planar transistor.

Structure

• Low frequency


• Amplifier High


• Speed switching
