Dual Line CAN Bus Protector
Our adventage
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt forproduction outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Description
The NUP2105L has been designed to protect the CAN transceiver in high-speed and fault tolerant networks from ESD and other harmful transient voltage events. This device provides bidirectional protection for each data line with a single compact SOT-23 package, giving the system designer a low cost option for improving system reliability and meeting stringent EMI requirements.
Features
● IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact)
● IEC61000-4-4 (EFT) 40A (5/50ηs)
● IEC61000-4-5 (Lighting) 8.0A (8/20μs)
● 350 Watts Peak Pulse Power per (tp=8/20μs)
● Working voltages : 24V
● Low clamping voltage
● Low leakage current
Applications
● Industrial Control Networks
●Smart Distribution Systems
● Automotive Networks
●Low and High-Speed CAN
●Fault Tolerant CAN
