Description

The 6N138 and 6N139 series combine an AlGaAs infrared emitting diode as the emitter which is optically coupled to a silicon high speed integrated photo-detector logic gate with a strobable output in a plastic DiP8 package with different lead forming options.

A separate design between photodiode and transistor reduces the base-collector capacitance of the input transistor which improves the speed by several orders of magnitude over conventional phototransistor optocouplers.

Features

●High isolation 5000 VRMS

●DC input with transistor output

●Operating temperature range -55°C to 100℃

●REACH compliance

●Halogen free(Optional)

●MSL class 1

●Regulatory Approvals

●UL-UL1577

●VDE-EN60747-5-5(VDE0884-5)

●CQC-GB4943.1,GB8898

●cUL-CSA Component Acceptance Service Notice No. 5A

Applications

●Low current line receivers

●Current loop receivers

●Out interface to CMOS-LSTTL-TTL

●Pulse transformer replacement

●Computer-peripheral interface
